Large range of spraying quantity can meet the spreading requirements for variety of aggregates.
Hydraulic telescopic design enabled the flexible adjusting of spreading wide.
The openness of aggregate door and spreading speed are proportionally controlled. Spreading rate will not be affected by the truck speed.
Belt feeding of the material is controlled by level indicator. Materials feeding can be finished automatically.
Auger conveying of the material is controlled also by level indicator. Materials can be conveyed continuously.
The auger and roller are driven by independent motor and will not interfere with each other.
Hydraulic driven introduced in the walking system. The moving of truck is stable and the travel speed can be adjusted easily. Cleaning, repairing and maintenance of equipment tends to be convenient.
The receiving hopper introduces hydraulic control, which reduced the residual amount of aggregates after spreading work.
Self-locking tow hooks enabled the convenient connection and disconnection of spreader and dumper during spreading. The height of hooks can be adjusted accordingly to catch with the traction rod on dumper.
High efficient diesel engine can meet the working requirement in different environment and with different loading capacity.
Full hydraulic steering system applied on the truck makes the turning to be more flexible.
Stable and high efficient hydraulic braking system applied on the truck makes braking performance of the vehicle to be more superior.
Movable seat (operation console) applied to improve the vision of operator. Operation turns to be more intuitive.
The spreader features a large range of spraying quantity, making it compatible with a variety of aggregate types. Its adjustable settings allow it to meet diverse spreading requirements across different road construction applications.
Yes. The hydraulic telescopic design allows flexible and real-time adjustment of the spreading width, enabling the operator to adapt to different road widths and project requirements without stopping the machine.
No. The openness of the aggregate door and spreading speed are proportionally controlled, so the spreading rate remains consistent and will not be affected by changes in truck speed, ensuring uniform material distribution.
Yes. Both the belt feeding and auger conveying systems are controlled by level indicators, allowing materials to be fed and conveyed automatically and continuously without constant manual intervention.
The spreader uses self-locking tow hooks that allow fast and convenient connection and disconnection from the dumper during spreading. The hook height is also adjustable to match the traction rod height of different dumper models.
The spreader is powered by a high-efficiency diesel engine suitable for various environments and loading conditions. It uses a full hydraulic driving system for smooth travel with adjustable speed, full hydraulic steering for flexible turning, and a reliable hydraulic braking system for superior braking performance.
