The smart model introduced the Intelligence system, enabling end users to monitor plant working conditions in real-time and send/receive data. Factory servers connect directly to users for timely after-sales service.
Considering powder, smoke, and noise pollution caused by asphalt plants, feasible solutions and components are provided to meet various environmental protection standards tailored to client requirements.
Optimized cold feeder bin, dry drum, hot elevator, vibrating screen, and weighing system make operation significantly easier, achieving higher productivity, reliability, and mixing quality.
Reserves connection ports for additive warm mixing and hot recycling, ensuring the plant is suitable for future technological upgrades and process revolutions.
Highly integrated modular design. Parts are preassembled in the factory so only modules need assembly on-site, saving assembly time, foundation costs, and boosting overall efficiency.
Each part features an independent weak current control box with quick-latch operation room connections. Heavy current input terminals, output terminal quick clamps, and air system connections are factory preassembled.
| Parameter | KDG2000 | HDG2000 | HDG3000 | HDG4000 | HDG5000 |
| Number of batching hoppers | 5 | 5 | 6 | 6 | 6 |
| Batching bucket single bucket volume (m³) | 10 | 10 | 15 | 15 | 18 |
| Rated production capacity (t/h) | 160 | 160 | 240 | 320 | 400 |
| Total installed capacity (kW) | 400 | 400 | 678 | 852 | 1046 |
| Stirring pot capacity (Kg) | 2000 | 2000 | 3000 | 4000 | 5000 |
| Dimensions (m) | 32*32*20 | 32*32*20 | 35*35*21 | 45*38*22 | 42*40*22.5 |
| Finished product silo capacity (optional) (t) | — | 40 | 50 | 50/100 | 50/100 |
| Bag dust removal area (m³) | 660 | 660 | 960 | 1200 | 1660 |
| Measurement accuracy | Aggregate: ± 0.3%; Filler: ± 0.2%; Asphalt: ± 0.1% | ||||
| Number of Asphalt Tanks (pcs) | 2 | 2 | 3 | 4 | 4 |
| Number of heavy oil tanks (pcs) | 1 | 1 | 1 | 1 | 1 |
| Heat transfer oil furnace | 600,000Kcal | 600,000Kcal | 800,000Kcal | 1,000,000Kcal | 1,000,000Kcal |
The rated production capacity ranges from 160 t/h (models KDG2000 and HDG2000) up to 400 t/h (model HDG5000), catering to projects of various scales.
Our plants achieve high measurement precision: Aggregate accuracy within ± 0.3%, Filler accuracy within ± 0.2%, and Asphalt accuracy within ± 0.1%.
The intelligent system connects to factory servers, allowing operators to monitor working conditions in real-time, handle operational data, and receive prompt remote technical support.
Yes, environmental protection options are integrated to minimize powder, smoke, and noise emissions. The bag dust removal area ranges from 660 m³ to 1,660 m³ depending on the model.
No, the machinery features a highly integrated modular structure with factory preassembled components, allowing quick site assembly, fast electrical connections, and reduced setup costs.
