China Slurry Seal Paver Factory Manufacturers, Factory

Slurry seal paver is a kind of intelligent road maintenance machine specially designed by our company on the basis on absorbing advanced technology. This machine can be used in the slurry seal/micro surfacing road maintenance project and also the lower surfacing sealing of high class road and bridge surface treating.

This vehicle is made up of chassis, mixture rationing system, mixing system, paving and slicking system, hydraulic drive system and automatic control system and so on (see as figure 1). The construction process is controlled by compute, with simple operation and accurate ration.

Send Inquiry

Product Description

Features

Chassis Power Utilization: Makes full use of the extra power of the truck chassis main engine. No auxiliary engine is designed on the truck.

High Intelligence: Equipped with auto control techniques. Operators input paving thickness, width, and mix proportion; the computer executes all parameters automatically.

No Re-calibration Needed: The metering system requires no re-calibration even when changing the mix proportion.

High Precision Measuring: Imported monitoring and metering components for aggregate, filler, water, asphalt, and additives guarantee construction quality.

Qualified Paving System: 4 telescopic spreading screws with adjustable speed and direction ensure paving quality without segregation or remixing needs.

Adjustable Specifications: Paving width adjusts freely from 2.4m to 4.2m; paving thickness adjusts freely from 5mm to 15mm.

Versatile Applications: Suitable for slurry seal, micro surfacing road maintenance, and lower surfacing sealing of high-class roads and bridges.

Automatic Warning Device: Integrated alarms automatically trigger or stop the system when aggregate, water, or asphalt is nearly depleted.

User-Friendly Interface: Main construction parameters can be easily configured and monitored throughout the paving operation.

Technical Parameters

Parameters	Unit	Standard Value
Aggregate bin capacity	m³	12
Emulsified bitumen tank capacity	L	3600
Water tank capacity	L	3600
Additive tank capacity	L	250
Fine material tank capacity	L	600
Fiber box	No.	8 (Optional)
Total mass	kg	31000
Full-load axle load weight	kg	2×6400 / 2×8950
Overall size	mm	11250×2500×3650
Paving width	mm	2400~4200
Paving thickness	mm	5~15
Operating speed	km/h	1~3
Maximum rating productivity	kg/min	2850
Engine capacity	kW	247
Maximum running speed	km/h	77

Delivery And Service

Frequently Asked Questions

What are the adjustable ranges for paving width and thickness?

The paving width can be adjusted freely between 2400 mm and 4200 mm, while the paving thickness ranges from 5 mm to 15 mm to meet various construction requirements.

Does this equipment require an auxiliary engine?

No auxiliary engine is required. The machine fully utilizes the extra power output from the truck chassis main engine.

What applications is this paver suitable for?

It is designed for slurry seal and micro surfacing road maintenance projects, as well as lower surfacing sealing for high-class roads and bridge surface treatments.

How does the auto-control system handle mix ratio changes?

Thanks to the advanced auto-control technology, no re-calibration of the metering system is required even when changing the mix proportion.

What safety mechanisms prevent material running out during operation?

An automatic warning system monitors the aggregate, water, and asphalt levels, automatically triggering an alarm or stopping the machine when materials are nearly depleted.
