| Name | Unit | Value | Remark |
|---|---|---|---|
| Container volume | L | 16000 | - |
| Dimension (L x W x H) | mm | 9105 x 2550 x 3365 | - |
| Spreading width | mm | 500 ~ 2500 | Adjustable |
| Spreading density | kg/m² | 3 ～ 40 | Adjustable |
| Spreading accuracy | % | ±5 | - |
| Speed working | km/h | 2.6 | - |
The machine features a patented full automatic control system. The spreading rate per square meter remains constant and is not affected by changes in truck driving speed.
The unit comes standard with both a dedicated bag filter device and a dust cover, effectively preventing environmental dust pollution during the binding agent spreading process.
Yes, the spreading width is adjustable between 500 mm and 2500 mm, while the spreading density can be set between 3 and 40 kg/m² depending on project requirements.
No re-calibration is required for the metering system. Operators simply enter the specified spreading parameters into the digital system.
Only one truck driver is needed inside the cab to manage and complete the entire spreading process safely and efficiently.
The machine is built with an arch breaker to prevent material bridging/camber, alongside an integrated empty and overfilling alarm warning indicator system.
